parts with common edges can be added as a whole;
Lead check: automatically check whether there is an error in the addition of lead,
and can correct the error;
Punching in the center of the hole: the center of the hole is punched and cut;
Maximum outer circle diameter: set the outer circle diameter less than or equal to
how many is suitable for small hole center perforation.
2. compensate
Compensation is implemented to prevent cutting defects caused by laser or flame
during the cutting process. The width of these defects should be measured based on
the actual cutting results. The compensated cutting path is displayed in green on the
drawing board, while the original outline is shown in white. During processing, the
system will follow the compensated path. It is important to note that the original
graphic (white line) after compensation will not be processed; it is only displayed on
the drawing board for operational convenience.
(The white figure is the original figure, and the green figure is the
compensated trajectory)
