Enable Port Red Light Marking
Red Light Style
Graphic External Rectangular Box
Red Light Speed
X Offset X
Y Offset Y
X Size Scale X
Y Size Scale Y
Built-in Red Light Mode
Red Light Preview
OK
Close
Figure.9-10 Red Light
Red light style: Used to select the red light to display the bounding rectangle
of the figure or the outline of the figure.
Red Light Speed: It indicates the system movement speed in case of red light
pointer.
Offset Position: It indicates the system movement offset position in case of
red light pointer and may be used to compensate the position error between
red light and actual laser.
Size Scale: It refers to the size deviation between red light and laser, by
adjusting which the two can completely coincide.
