Advanced Configs Parameter Area:
Jump Speed: Set a jump speed corresponded by the current parameter.
Jump Position: Value of Jump Position TC. Jump position delay value.
Jump Distance: Value of Jump Distance TC. Jump distance delay value.
After each jump movement, the system will delay some time, and then execute
the next command. The actual delay time is calculated by the following
formula:
Jump TC = Jump Position TC + Jump Distance × Jump Distance TC
Jump delay = jump position delay + jump distance × jump distance delay;
End Point Compensation: This parameter requires being set only when the
end point fails to be put in place by TC parameter adjustment during
high-speed marking, by means of proceeding to marking a straight line with
length of end point compensation distance at the end of marking compulsively.
Negative value is supported.
End Point: Generally, this parameter does not need to be set. Only in
high-speed machining, when the delay parameter cannot be adjusted to make
the end point in place, this value is set to force the marking of a straight line
with the length of the compensation distance of the end point at the end of
machining. Negative values are acceptable.
Acceleration Distance: This parameter may be set properly to eliminate the
uneven dotting at initial marking segment.
Dotting Time: It indicates light emitting time of each point in case that point
objects exist.
Vector Dotting Mode: It indicates to compulsively specify the fixed pulse
number given out by the laser during each point marking.
Add Point at the End: It is used to solve the problem of laser end shining. The
software will automatically add points at the end of each pen, but will not
display it as an object.
Quantity number: Quantity number of points added at the end.
Distance: Distance between the points added at the end.
Dotting Time: Marking time for each point added at the end.
Dotting Times: Marking times for each point added at the end.
