Number of Completions
Total Time
Red Light Indicator
Marking
Parameters
Exit
…… Marking Not Started......
，：
In the dialog box, the data items are described as follows:
Total Number: The total counts that the marking command should be
executed. If checking the “Continuous”, the marking number will not be limited
by the total number;
Rotary Axis：Choose which axis to use；
Continuous Mark: If it is checked, it will not be controlled by the total number,
and it will perform continuous marking for graphs or text contents displayed in
the workspace.
Mark Selected: If it is checked, only those selected graphs will be marked;
otherwise, all the graphs will be marked;
Input trig port marking: Specify an input port and the marking can be
triggered through the IO port.
Overall Marking of Graph: Mark the individual graph or text as a whole at a
time, and after marking an individual graph, rotate for an angle.
Press icon: After each engraving, rotate the z-axis coordinate value (angle) of
the graph. Different graphs can set different rotation angles
Increment: The angle that the column should rotate after mark each figure. It
is the angle interval between two adjacent figures
Increment mark: Rotate the mark according to the set angle interval.
360 degree mark: Selected to mark the figure on the column evenly
360 degree rotating mark: Set how many times to mark the figure in a week;
