5000/ Maximum Speed 5000 pulses/second
100 Acceleration Time 100 ms
700 / Motor Startup Speed 700 pulses/second
6400 / Motor Running Speed 6400 pulses/second
Zero
5000 Return-to-origin Speed 5000 pulses
100 Return-to-origin Timeout 100 seconds
Accurate Back to Zero
0.2 Backlash Compensation 0.2 mm
0 Dislocation Compensation 0 mm
Test
OK
Close
Invert: It refers that the expansion axis rotates in the opposite direction. When
it is checked, it means the expansion axis will invert;
Reversal: It refers to the movement in the opposite direction of the extension
axis; when checked, it indicates that the extension axis is reversed.
：。
Print by Facing to Characters: Change the sequential order of text marking.
Character to meet：Change the sequence of text marking.
Pulses per Round: The pulse (subdivision of driving motor) numbers each
round that the expansion axis rotating. It can be set according to the motor
parameter.
number of：
Distance per Round per revplution：The distance each round that the
expansion axis rotating，Click the setting button "..." to calculate a more
accurate distance per round.
