5.7. Resort Sorting
Select this command in the modify menu or select
from the main
interface。The software will mark through your chosen direction
Select this command in the modify menu or select
from the main
interface. Draw multiple objects, click Sort, the direction of blue arrow in the
working area indicates the current marking order. The sorting icon appears
above the main interface, as shown below
Fig.5-15 Resort Sorting
5.8. Align alignment
Command “Align” will be available only when more than one object is selected
in the workspace. “Align” is used to align the objects users select on the
two-dimensional plane. There are several ways to align:
Center point alignment: All objects align center. This way may cause
moves on both horizontal and vertical directions.
Align Left: All objects align left.
Align Right: All objects align right.
Top Align up: All objects align top.
Bottom Align below: All objects align bottom.
Vertical Centered vertically alignment: All objects align vertical. These three
ways above only support to move objects on horizontal direction.
Centered Horizontal alignment: All objects align horizontal. These three
ways above only support to move objects on vertical direction.
：
，、，，。
Graph Equidistance Function: After selecting the object graphs, clicking
