Fig. 5-6 Rotation Setting Box
Transformation
45.000 Angle 45.000 degree
Center
X -38.164 X -38.164 mm
Y -41.646 Y -41.646 mm
Relative Center
Apply to Copy Object
Apply
Angle: Angle to rotate.
Angle: Represents the angle to rotate for the currently selected object.
Center: The coordinates of the currently selected object’s datum mark.
This function is the same as the Center which is introduced in object label of
properties toolbar in Chapter 2.
In absolute coordinates, this function is equivalent to the X and Y functions in
