Rectangle: The graph according to rectangle array.
Matrix ：Indicates that the pattern will be arranged in a rectangle.
Circle array: The graph according to circle array.
: Present the graph in undirectional array as per marking sequence.
: Indicates that the figures after the array are arranged individually from
left to right，At the same time the processing sequence is determined.
: Present the graph in bidirectional array as per making sequence.
：Indicates that the pattern after the array is arranged in two directions from left
to right and then from right to left, It also determines the processing sequence.
Array Num: The row number.
Array Num: The column number.
Array: The space between two objects on X direction.
Horizontal number：Array is the number of arrays in the X direction.
Array: The space between two objects on Y direction.
Vertical number：Array is the number of arrays in the Y direction.
Lateral spacing：The distance between the x-direction graphics after the
Array.
Vertical spacing：The distance between the x-direction graphics after the
Array.
Calculate by Offset Distance: The space of the graphs is calculated by offset
distance. (Fig. 5-3 (a))
