YDFLP-CL2-200-1/5-A&YDFLP-CL2-300-1/5-A User Manual
instability might occur during material processing if using K9 glass optical field lens. Fused silica
lens is recommended.
6) Please keep the fiber laser source clean especially the laser output window. Please
remember to cover the output window when it’s exposed to the open environment. Dust on the
window will cause heat and damage the lens, which results in output power decrease even laser
damage.
7) Please make sure that the power is off before installing and uninstalling.
8) Please do not look at the output window anytime when power on, and wear laser safety
goggle when operating the fiber laser.
9) YDFLP-CL2-200-1/5-A&YDFLP-CL2-300-1/5/10-A contains 12 wave-forms: 13ns,
20ns, 30ns, 45ns, 60ns, 80ns, 100ns, 150ns, 200ns, 250ns, 350ns, 500ns.Other pulse width is
available for customization request.
1.4 YDFLP CL Series Product Naming Convention
Table 3. Naming Convention for Pulsed Fiber Laser
YDFLP – XX – XX – XX – X – X
1 2 3 4 56
1. Product Name：Ytterbium Doped Fiber Laser Pulse (YDFLP)
2. Product type：CL: Cleaning Series 1 CL2: Cleaning Series 2, usually an upgraded version
of CL
3. Average Output power
4. Fiber characteristic:
Numbers such as 1, 5, 10, 15, 50, and 100 represent different types of fiber characteristics
5. Thermal Solution:
A：Air-cooled
W：Water-cooled
3
    "
