User Manual
YDFLP-CL2-200-1/5-A&YDFLP-CL2-300-1/5/10-A
1. Product Introduction
1.1 Product Description
JPT pulsed fiber laser adopts master oscillator power amplifier (MOPA) structure, in
which the master oscillator uses semiconductor laser as the seed source, and the power
amplification is realized by traveling wave fiber amplifier. MOPA structure pulse fiber laser is
used to output pulse beam by directly modulating single-mode semiconductor laser. Its pulse
width is adjustable, its waveform can be edited, it has continuous mode, and its frequency range
is wide, and its peak power is high. The pulse timing can be precisely controlled with the later
stage pump. The controllable parameters are many, which greatly expands the application
range of related pulse laser, and provides an ideal light source for industrial laser marking and
other applications.
The Series fiber laser control with standard DB25 interface and powered with 48V
DC,which makes it a good compatibility. Compared with similar products, the Jet pulsed fiber
laser can adjust the pulse width and frequency within a certain range, and can maintain a stable
peak power output. CL series lasers adopt lightweight design for the laser output part, which
is particularly prominent in applications such as laser cleaning.
Photograph of typical YDFLP-CL2-200-1/5-A&YDFLP-CL2-300-1/5/10-A fiber lasers is
shown in Fig.2 (For the specific appearance, please refer to the actual product shipped):
Figure 2. YDFLP-CL2-200-1/5-A&YDFLP-CL2-300-1/5/10-A
