Hikrobot Machine Vision Software User Manual
Note
You can click View on the prompt popped up when saving completes to go to the saving
path of the project file.
Open Project File
You can open a project file to restore the saved feature settings to the cameras with
matched serial numbers. Two scenarios are involved in the opening of a project file.
Scenario 1: The Software Has been Running
When the Software has been running, you can perform one of the operations in the
following list to open a project file.
● Click File → Open Recent and then select a recently saved project file to open it.
● Click on the control toolbar or click File → Open to open the Selected Project File
window, and then select a project file from the PC, and finally click Open.
Scenario 2: The Software is Not Running
Double-click the project file, and then the Software will run and the cameras with the
matched serial numbers will be connected automatically, and the feature settings
information contained in the file will be imported to the cameras as well.
Open Local File
You can open local images and video files to view them on the display window of the
Software. For details, see View Local Image and Video.
3.2 View
You can adjust the image quality of the live video by setting the display mode, filtering
mode, vertical synchronization mode, and rendering engine.
Note
The settings will be effective for all cameras on the Software.
Set Display Mode
You can click View → Display Mode and then select 30 fps or 60 fps to set the image
frame rate to 30 frames per second or 60 frames per second respectively.
Note
The larger the image frame rate, the better the image quality.
Set Rendering Engine
You can click View → Rendering Engine to set the rendering engine mode to D3D or GDI.
16
