Machine Calibration
Machine calibration
Vertical Check
1. Click on "Head Spacing" - Click on "Print"
2. As shown in the figure below, the longitudinal offset is about
"+2", you need to fill in the "original value + 2" in the vertical
calibration "H2" edit box, and then click the "Apply" button to
save, and then click "Vertical Calibration", and then Print a
vertical calibration chart to confirm whether the step is at the
zero position.
3. If it is not at the "0" point, add or subtract according to the
printed calibration chart until the calibration reaches the "0"
point
4. When modifying the longitudinal calibration, the No. 1 head is
used as the benchmark, and the data of the No. 2 head is
modified sequentially without modifying the data of the No. 1
head
