150W Power Supply Model: HY-T150
Ⅰ. Main Features
1) Good compatibility: It can be applicable to 150W,130W,120W,100W laser tubes
2) When input AC220V and output current up to 38mA,The voltage can be up to 25KV.
3) Fast Response speed:it can enlarge laser power observably and prolong laser tube's service life.
4)Easy Control: High level or low level all suitable to Control.
5)Open circuit protection Function: when the earth connection is under good situation,Power can be
short time work in open state, it Can avoid the laser tube burst damage caused by laser power supply,
prolong the laser tube's service life.
6)One button to test the output laser manually.
7) TTL Signal indication, water though signal indication, and laser output indication.
8) Application: Sculpture and cut acrylic, fabric,double color sheet ,rubber etc.
II. Specification：
Input
Input Voltage
AC220V or AC110V（to be specified when placing order）
AC frequency
Cold Surge Current
47—440HZ
≤60A(AC220V Input)
≤30A(AC110 Input)
Current Leakage
≤0.7MA（AC220V Input） ≤0.4MA(AC110V Input)
