RDEMarkVision Operation Manual
Line by line feeding: the feeding device sends materials one by one to the place in a way of feeding.
Progressive feed compensation: there may be some errors in the use of feeding devices for progressive feed.
Reset speed: When the machine starts, return to the original speed, if the machine is larger, can be set reset speed
on the high side, but not too large.
X, Y, Z, U boot reset: you can set up whether each single shaft is reset during boot.
Array processing mode: two way array and one way array can be selected. Bidirectional walk array: that is,
cutting the array back and forth in sequence; one-way walk array: cutting the array from one direction to another
all the time. When the one-way walking array is selected, the action mode of each array unit is exactly the same,
and the action fluency is completely consistent, but it takes a little time than the two-way walking array. The
default choice is bidirectional array.
Location of return: mechanical origin, location and non return position. This parameter determines the position
where the carving head stops after each work.
Focal length: corresponding panel auto focus operation.
Reverse gap X, Y: used to compensate for the reverse gap caused by machine transmission.
Knife lifting position: the position of the cutter head when the machine starts carving.
Location of the cutter: the position of the cutter head when the machine is finished.
Docking position: the position of the carving head after machine carving.
Cutting speed: the speed of the cutting head of the carving head when the machine is engraving.
Pre processing delay: waiting time before machining.
2.1.3 information
Click on the file, click the parameter settings, click the system information as shown below:
View motherboard version number and upgrade motherboard
