including 914mm, 1070mm, 1270mm, 1520mm and other specifications. Materials, pictures and sheet rolls should be
placed in appropriate places in the central area, and it should be ensured that they are put in the same scale.
(2) The main power supply should be turned on.
(3) Cold laminating should be selected in case of high temperature indoors. If the indoor temperature is relatively low or
fails to reach the required temperature for laminating, the button of "rubber roller heating" can be pressed, and then the
buttons of "temperature setting" and "heating" should be pressed to set the desired temperature. Then please wait for
temperature rise and go through the next step.
(4) After the heating process is over, please press the "pedal" button and the button of "laminating", and set the speed as a
low gear, such as gear 1.
(5) Please follow the operation schematic diagram to strip off the film and lining paper and make the picture and film fit
each other trimly, and then press the pneumatic switch.
(6) Please stamp the pedal switch to slowly conduct laminating for a short while, use the adhesive tape to stick the finished
product of laminating to the sheet roll on the finished product collecting axle, relocate the cutting knife and continue to
stamp the pedal switch and conduct laminating.
(7) In the process of laminating, please check carefully whether the phenomenon of arch camber appears. In case of arch
camber, it is necessary to adjust the tightening force of the picture placing core axle, and the tightening force of the lining
paper collecting core axle should be strengthened if the speed of lining paper collection is too slow. The rotary knob can be
slightly adjusted through adjusting the cutting knife to rectify the deviation of cutting.
(8) After the laminating is in a normal state, please press the "pedal" button again. Continuous laminating can be conducted,
and the speed of laminating can be accelerated after the indicator light of pedal control is off.
(9) When the laminating is finished, the button of "stop" can be pressed to stop the operation and start the laminating of the
next roll of materials.
4. Maintenance and service
(1) Please check whether the surface of the machine's rubber rollers is clean for each time of startup. If the machine has
faults or abnormal voice, please continue to use the machine only after timely analysis of causes and troubleshooting to
make the machine restore the normal state.
(2) During the process of cleaning the heating rubber rollers or machine maintenance, the rubber rollers can be positively or
negatively rotated through pressing the forward button or backward button. There are always some residual binding agents
on the heating rubber rollers in the process of laminating of the machine. The duster cloth dipping in alcohol can be used to
clean the surface of the rubber roller. It is strictly prohibited to use sharps (such as blades) to touch or scrape the surface of
the rubber roller, which will influence the flatness of the rubber roller and the effect of laminating.
(3) Please close the heating mode after using the machine, and stop the rotation of rubber rollers and turn off the power after
the temperature drops to the indoor temperature.
(4) If the laminator is used on a daily basis, engine oil should be added to the transmission chain for one time per month for
lubrication, and the transmission chain should be cleaned every half a year. Overall inspection of the machine shall be
conducted for one time in each year to find out problems and timely solve them.
5. Common fault and troubleshooting
