Horizontal
spacing
calibration
Vertical spacing
calibration
Colour
calibration
Guangzhou Senyang Electronic Technology Co.
corresponding value increase
or decrease to the two-way
calibration box.
method of operation:
Print the horizontal spacing
test strip, when the two-way
value is accurate at "0", the
line is consistent, if not
consistent, then find the
consistent group of lines
according to the trend, write
the corresponding value
increase or decrease to the
two-way calibration box.
Double-head vertical spacing:
Control two heads to
overlap together in the Y
direction.
First 1 / Head 2 internal
vertical:
The control head interior
overlap together in the Y
direction.
method of operation:
The default is "0", select the
nozzle print calibration bar,
view the corresponding line
group in CH0 CH15 to fill in
the corresponding box.
11
