option is on, job height and job width in the General
tab will update as the number of copies is changed.
Panel Tools
The tool bar provides tools to automatically tile the job.
Panel Mode locks columns and rows so that the entire column
or row can be adjusted as a group.
Auto Panel creates a panel that includes all selected objects. If
no objects are selected, all of the objects in the design will be
included. If the design is too large to fit on the selected
material, it will automatically be tiled so that each tile is the
maximum possible size.
Auto-panel does not attempt to panel the entire page,
just the design or the selected objects.
Panel to Border tiles the entire design page. If the design is too
large to fit on the selected material, it will be tiled so that each
tile is the maximum possible size.
Engrave Dialog – Options Tab
The Options tab allows you to set a number of options for engraving jobs.
© 2006 SA International
Send all tools
Check to engrave all tools and select how each tool will be
processed.
Single Job The job is sent as a single file and processed
using the same panel size for all tools.
Multiple
Jobs
A separate job file is created for each tool but
they are still processed using the same panel size
for all tools.
