Divides the job into a specified number of evenly sized
columns.
Divides the job into a specified number of evenly sized rows.
Even Columns
Even Rows
Divides the job into a specified size of columns, starting from
the left side.
Divides the job into a specified size of rows, starting from the
bottom.
Preventing Tiles from Being Output
Do one of the following:
• Double-click on the tile in the preview pane.
• Right-click on the tile in the preview pane.
Disabled tiles are marked with a hash pattern.
Disabled tile
Specifying column width Specifying row height
Specifying Overlap between Tiles
You can specify the amount of overlap
between rows and columns. By
overlapping, you can eliminate any
gaps between the tiles when
assembling the final output. Overlap is
measured as the total amount two rows
or columns overlap.
Horizontal
Overlap
Vertical
Overlap
Check to create an overlap on the vertical edges of tiles.
Check to create an overlap on the horizontal edges of tiles.
The width of the overlap.
To enable a disabled tile, double-click or right-click the disabled tile a
second time.
One tile in each job must always be enabled. If you try to disable all of the
tiles, one of the other tiles will become enabled again.
© 2006 SA International
150
