Even Columns
Even Rows
Divides the job into a specified size of columns,
starting from the left side.
Divides the job into a specified size of rows, starting
from the bottom.
Preventing Tiles from Being Output
Do one of the following:
• Double-click on the tile in the preview pane.
• Right-click on the tile in the preview pane.
Disabled tiles are marked with a hash pattern.
Disabled tile
Specifying column
width
Specifying row height
Specifying Overlap between Tiles
You can specify the amount of overlap between
rows and columns. By overlapping, you can
eliminate any gaps between the tiles when
assembling the final output. Overlap is measured
as the total amount two rows or columns overlap.
Check to create an overlap on the
vertical edges of tiles.
Check to create an overlap on the
horizontal edges of tiles.
The width of the overlap.
Horizontal
Overlap
Vertical Overlap
Tiling All Copies Individually
Tile all Copies
Check to show all copies in the preview so that the tiles can be
adjusted on each copy. When this option is on, job height and
job width in the general tab will update as the number of
copies is changed.
To enable a disabled tile, double-click or right-click the disabled tile a
second time.
One tile in each job must always be enabled. If you try to disable all of the
tiles, one of the other tiles will become enabled again.
© 2006 SA International
142
