Auto-tile: A tile will automatically be created that includes all
selected objects. If no objects are selected, all of the objects in the
design will be included. If the design is too large to fit on the
selected media, it will automatically be tiled so that each tile is the
maximum possible size. Auto-tile does not attempt to tile the entire
page, just the design or the selected objects.
Tile to Border: The entire design page is automatically tiled. If the
page is too large to fit on the selected media, it will be tiled so that
each tile is the maximum possible size.
Resizing the Panel
The panel defines the area of design that will be processed for output.
Elements of the design that are outside the bounds of the panel will not be
cut.
You can resize the panel by dragging the panel border or using the Panel
Size group to numerically enter the panel size.
Resizing the Panel with the Mouse
1 Move the cursor on top of the small red
squares along the panel border.
2 Click and drag to resize the panel.
Resizing the Panel Numerically
Adjust the following parameters:
The width of the panel.
The height of the panel.
Margin around the panel.
Tiling the Job Using the Preview Area
Adding New Tiles to the Panel
1 Move the mouse cursor on
top of the panel border.
2 Click and drag towards the
center of the panel to add a
new panel.
Resizing Existing Tiles
1 Move the mouse cursor on
top of the tile border.
2 Click and drag to resize the
tile.
Panel border
Tile border
Tiling the Job Using the Tile Group Box
The Tile group allows you to specify the tiles numerically.
1 Select the tile you want to resize in the preview area.
2 Enter the new size.
The width of the selected tile.
The height of the selected tile.
Tiling the Job Evenly
To tile the job evenly, check the tiling option you want to perform and
enter the desired number or the size of rows and columns.
Adjust the following parameters:
Divides the job into a specified number of evenly sized
columns.
Divides the job into a specified number of evenly sized
rows.
