communications.
Material width.
Material height.
Sending Mode
The Send List allows you to select what to do with the job once it arrives in
the Production Manager queue.
Send now
The job is automatically processed and sent to the output
device.
Hold in list
The job stays in the Production Manager queue until it is
manually sent to the output device from the Production
Manager window.
Save to file
The job is processed and saved as a native file.
The Send Now mode is not available if the output device is inactive or the
Production Manager is on another computer on the network and the option
Allow remote Send Now/Interactive is not enabled in the Production Manager
Preferences. See the Production Manager User Manual for more information.
Position Settings
The Position group box allows you to specify where on the media the job is
output.
Horizontal offset distance.
Vertical offset distance.
Activates Interactive mode. Interactive mode allows you to
dynamically interact with the tool head by moving the tool as
you change the position of the job on the preview area.
Show me tool draws a bounding box of the job without
lowering the tool.
Positioning the Job by Clicking and Dragging
1 Choose Select tool from the toolbar of Cut/Plot dialog.
2 Click and drag the preview to a new position.
Click…
…and drag
Size Settings
The Size group box allows you to change the size of your output.
Width of the output.
Height of the output.
Scale ratio.
Fit to media
Scales the job proportionally so that it is as large as possible
while still fitting within the printable area of the output media.
Copies Settings
The Copies group box allows you to set the number of copies and the
spacing between them.
The number of copies.
The amount of space between the copies.
Copy
Spacing
The copies are automatically
positioned to optimize the
media usage.
Positioning Tools
The Positioning tools allow you to rotate, mirror or position the job.
The job is placed at specified distances from
the right edge and the leading edge of the
media.
The job is centered on the leading edge of
the media.
The job is centered in the length and width
of the media.
and
drag
