Connecting to PhotoPRINT Server on another
Computer on your Local Area Network
1 Make sure that neither Production Manager nor PhotoPRINT
Server are running on your computer.
2 Create your design in the design software.
3 Click on either the Cut/Plot or RIP and Print button in the
toolbar.
4 If the Select a Production Manager dialog does not appear, select
Other from the Setup List in the top left corner of the dialog.
5 Select On another computer (Network).
6 Click OK.
 If Production Manager is running on the computer, the software will
connect to that copy of Production Manager instead of PhotoPRINT
Server.
3 Find out the TCP/IP address of the remote computer.
4 To determine the TCP/IP address of a Windows computer,
from the command line type IPCONFIG and hit Enter.
Windows IP Configuration
Ethernet adapter Local Area Connection:
Connection-specific DNS Suffix . : alias.com
IP Address. . . . . . . . . . . . : 10.1.1.134
Subnet Mask . . . . . . . . . . . : 255.255.255.0
Default Gateway . . . . . . . . . : 10.1.1.2
5 Create your design in the design software.
6 Click on either the Cut/Plot or RIP and Print button in the
toolbar.
7 If the Select a Production Manager dialog does not appear, select
Other from the Setup List in the top left corner of the dialog.
7 Select the copy of PhotoPRINT Server you want to connect to.
8 Click OK.
Once the software connects to PhotoPRINT Server, it will automatically
populate the Setup List with the available setups.
Connecting to PhotoPRINT Server at an Internet
Address
1 Make sure that neither Production Manager nor PhotoPRINT
Server are running on your computer.
2 Make sure that Production Manager is not running on the
remote computer.
8 Select On the internet address.
9 Enter the TCP/IP address of the remote computer.
10 Click OK.
Once the software connects to PhotoPRINT Server, it will automatically
populate the Setup List with the available setups.
Sharing a Hardware Key over a Local
Area Network
It is possible to run the design software on one computer and Production
Manager on a separate computer, using only one hardware key. The
computer that has Production Manager and the computer that has the
design software must be networked and TCP/IP must be installed and
working properly.
