Shenzhen RelFar Intelligent Technology Co., Ltd.
Chapter 3 Product Installation
3.1 Pipe connection
Cooling water circuit and auxiliary protective gas connection
6mm water pipe (outlet)
6mm air tube (inlet)
6mm water pipe (inlet)
Connection of cooling water and shielding gas and usage
requirements:
Note: Regularly used gases: Compressed air (oil-water
filtration required)
Regularly used gases are: argon, nitrogen and compressed air
(oil-water filtration required).
3.1.1 Cooling water
The 6mm air tube is connected. The main function is that the
excess heat is taken away by cooling through the internal
structural member water route when the heat is produced by the
7
