1
2
152050 9640
50 / 0.05 A
4
30
4
Hole for 2.9 x 9 self-
threading screws
14 • ACCESSORIES
• Current transformer
5,5
27
5,5
1
2
8
8
38
These transformers are used to measure currents of 50 ÷ 60Hz from 25A to 600A
(nominal primary current). The peculiar characteristic of these transformers is the high
number of secondary turns. This provides a very low secondary current, suitable for an
electronic measurement circuit. The secondary current may be detected as voltage on
a resistor.
CODE
Ip / Is Ø Secondary
n
OUTPUTS
Ru
Vu ACCURACY
Wire
2
TA/152 025 25 / 0.05A 0.16 mm n1-2 = 500 1 - 2
40 Ω 2 Vac
2.0 %
TA/152 050 50 / 0.05A 0.18 mm n1-2 = 1000 1 - 2
80 Ω 4 Vac
1.0 %
In
20
• ORDER CODE
IN = 50Aac
COD. 330200 OUT = 50mAac
IN = 25Aac
COD. 330201 OUT = 50mAac
• RS232 / TTL interface cable for configuration of GEFRAN instruments
N.B.: The RS232 interface for configuration from PC is supplied along with the programming software.
Connect with the instrument powered and with inputs and outputs not connected.
• ORDER CODE
COD. WSK-0-0-0
Interface Cable + CD
Winstrum
81503D_MHW_400-401_12-2010_ENG
