6 Select the plt job file and click Send Mark detection (Page 23 / 27) Contour Cutting Guide

16. Select the .plt job file and click Send.

Mark detection takes about 30 seconds before cutting.

Printing Multiple Jobs on a Single Piece of Media

Using Cut Server, you can output more than one job on a

single sheet or roll of media.

In your design application, simply output the printed portions of

the jobs one after another. The order you print the jobs in does

not matter. The printed portion of each job will be marked with

a barcode that will identify which contour cut job Cut Server

should use with that design.

Once the print jobs have been output, you can then output all

the cut jobs from your design application, sending them to Cut

Server. Again, it does not matter which order you output the

cut jobs in.

Next, load the printed output into the cutter and output the cut

jobs from Cut Server. As each cut job is output, Cut Server will

scan the barcodes the printed jobs until it finds the one that

matches the cut job. Cut Server will then cut the contour onto

that printed job.
