l PC and Multi-controller to concentrator.
Concentrator
input
output
PC
controller1 controller2
controllerx
1 PC connects the input of the concentrator. Multi-controller connects to the output of the concentrator.
2 Different IP address should be configured for every controller. But all of the IP address should be set
between 192.168.001.100-192.168.001.149
3 Then set the PC IP address between 192.168.001.2-192.168.001.049.
l PC and Multi-controller to concentrator. And the concentrator
connects to router.
1 PC and multi-controller connect to output on the concentrator.
2 Different IP address should be configured for every controller. But all of the IP address should be set
between 192.168.001.100-192.168.001.149
3 Configured step please reference to Single controller to PC with multi-NIC
    "
