6.8 CN4 reserved serial interface
CN4 reserved serial port interface is a 4-pin green terminal without wiring.
Chart 6.8.1 shows the definition of CN4 interface.
Pin Signal
1
OVCC
2
TXD
3
RXD
4
GND
Table 6.8.1
Definition
Description
+24V power supply, 500mA Power supply
TXD signal
Serial communication TXD signal
RXD signal
Serial communication RXD signal
GND
—
6.9 CN6 external start and safety lock interface
The CN6 interface is a 4PIN green terminal. Table 6.9.1 shows the
definition of CN6 interface.
Table 6.9.1
Pin
Signal
Definition
Instruction
Generally connecting to the start button switch on
1
GND
Reference ground
the welding head-
External start switch Generally connecting to the start button switch on
2
Start
input
the welding head+
The pin must be connected to the safety clamp and
Safety clamp signal
3
Injector
the safety clamp shall be clamped onto the metal
input
material before welding.
The pin must be connected to the nozzle of the
Safety lock signal
4
Interlock
handheld head. The nozzle touches the metal
input
material at the moment of welding.
