User Manual of Machine Vision Camera SDK Demo (VS2008)
Chapter 7BasedOnGenTL
The BasedOnGenTL is a sample program based on GenTL, it can load different CTI files for enumerating
corresponding devices, and realizing the functions of interface enumeration, device search, initialization,
image acquisition, and parameters control.
7.1 Interface Overview
The BasedOnGenTL interface includes five control modules (interface enumeration, device search,
initialization, image acquisition, and parameters control), one device drop-down list, and one image
display area.
7.2 Operation Procedure
Steps:
1. Click Enumerate Interface to browse repository.
2. Select required CTI file to load.
For example, select the MvProducerGEV.cti file in the directory: C:\Program Files (x86)\Common
Files\MVS\Runtime\Win32_i86.
3. Click Search Device to search the online device.
The online GigeVision devices appear in the drop-down list of Device field.
Note: If the user ID is not empty, the devices will be displayed as “device type” + “device name” + “IP
address”; otherwise the devices will be displayed as “device type” + “device model” + ”IP address”.
