Pulse input
F2e
mode selection
Command pulse string mode selection of position mode:
1- single pulse string pulse 12 27
positive logic
direction 13 28
2 – single pulse
pulse 12 27
string negative logic direction 13 28
3 - double pulse
CCW 12 27
2
strings positive logic CW 13 28
4 - double pulse
CCW 12 27
strings negative logic CW 13 28
5 - quadrature pulse phase A 12 27
positive logic
phase B 13 28
6 - quadrature pulse phase A 12 27
negative logic
phase B 13 28
72
