Installation Notices
Attention
¾ Only when this equipment is installed in the qualified electricity cabinet can it be used. The
construction of the cabinet must reach IP54 grade of protection.
¾ Paste sealing strips on the joint of the cabinet to seal all the cracks;
¾ Cable entry should be sealed while easy-to-open on the spot;
¾ Fan or heat exchanger should be adopted for the heat dissipation and air convection of the
cabinet;
¾ If fan is adopted, air strainer is a must in air inlet or air outlet;
¾ Dust or cutting fluids may have access to the CNC device via the tiny cracks and tuyere.
Therefore it is necessary to pay attention to the surroundings and air flow direction of the air
vent to make sure that the outflow gas is towards pollution source.
¾ 100mm space should be preserved between the back of the CNC device and the cabinet wall
for plugging cable connected with the device and for the ventilation & heat dissipation in the
cabinet.
¾ Space between this device and other equipments should also be preserved according to the
requirements.
¾ The product should be installed firmly and without vibration. During installing, casting,
knocking, striking, or loading on the product is forbidden.
¾ To reduce electromagnetic interference, power-supply components used should be above AC
or DC 50V and the space between cable and the CNC device should be preserved above
100mm.
¾ It will be better if the CNC device is installed on the position facilitating debugging and
maintenance.
