11.1.7. Parameter Setting of STONE GS Servo Driver
Para.
No.
F0f
F10
F00
Para. Name
Electronic gear
ratio numerator
Electronic gear
ratio
denominator
Control mode
selection
Value
Description
2 Electronic gear ratio of position mode: 4× pulse frequency
fed back by motor encoder = command pulse frequency× F0f
1
/ F10; value of F0f / F10 must be within 1/100~100.
(calculated with pitch as 10mm)
0: external speed running mode; make sure the value and
direction of motor speed according to the external analog
-10V ~ +10V signal of CN2-16, 17;
1: internal speed running mode; make sure the value and
direction of motor speed according to the setting of
parameter F33, F35, F37, F39 and the port status of CN2-9,
CN2-25;
2: position pulse running mode; receive the input of external
position command pulse and direction level signal;
3: jog mode; make sure the motor speed in terms of
parameter setting of F3b, and control the rotation direction by
the direction keystroke ▼ and ▲;
4: torque mode; make sure the value and direction of motor
2 torque according to the external analog -10V ~ +10V signal
of CN2-43, 1;
5～10: mixed mode; select mode according to the port input
status of CN2-24:
F00
Value
5
6
7
8
9
10
CN2-24 Interface Status
OFF (Mode One)
ON (Mode Two)
Position Pulse Mode
External Speed Running Mode
Position Pulse Mode
Internal Speed Running Mode
Position Pulse Mode
Torque Mode
Internal Speed Running Mode External Speed Running Mode
Internal Speed Running Mode
Torque Mode
External Speed Running Mode
Torque Mode
