11.1.6. Parameter Setting of FUJI FALDIC-β Servo Driver
Para.
No.
01
Name
Command pulse
numerator α
Command pulse
02
denominator β
03 Pulse string input form
Direction of rotation
04
switch
10
CONT1 signal
distribution
CONT2 signal
11
distribution
15
OUT1 signal
distribution
Parameter
27
write-protection
74 CONT Always ON 1
Value
Need
calculation
1～32767
Need
calculation
1～32767
0
0 or 1
1
2
1
0 or 1
1
Description
Command pulse numerator and denominator are
also equal to those of the electronic gear ratio.
α / β= encoder resolution× pulse equivalent×
mechanical deceleration ratio / screw pitch.
Typical value: encoder resolution 65536, pitch 5mm,
pulse equivalent 0.001, mechanical deceleration
ratio 1,
α / β=65536×0.001 / 5=8192 / 625,
So α=8192, β=625.
Set the input mode of pulse string as: instruction +
symbol, that is ‘pulse + direction’.
Set 0: Positive direction: Forward rotation (CCW);
Set 1: Positive direction: Reverse rotation (CW).
CONT1 is distributed as RUN (i.e. SON); if not
distributed, CONT1 will be auto ON if there is no
alarming when powered.
CONT2 is distributed as RST (i.e. servo alarming
clearance CLR).
When 12, 13, 14 are 0, that is CONT3, CONT4 and
CONT5 can’t be distributed as OT (over-travel) or
EMG (external emergency stop).
Set 1, OUT1 is distributed as a-contact point of
alarming output;
Set 2, OUT1 is distributed as b-contact point of
alarming detection.
Set 0, write-enable.
Set 1, write-protected.
Its initial value is 0, and it is set “1” here to enable
servo (RUN).
Note:
FUJI servo has no braking signal wire, so there is no need to set the parameters related to braking; you only need
to provide 24V brake power to pin Br (lead wire 5 and 6) of motor with braking.
