P2-16
Function setting
for digital input pin
DI7
X2X1X0
P2-17
Function setting
for digital input pin
DI8
X2X1X0
P2-21
Function setting
for digital output
pin DO4
X2X1X0
P2-22
Function setting
for digital output
pin DO5
X2X1X0
100
100
External EMG stop input is not used.
DO4 corresponds to pin 1 & pin 26, used
as clamping-position brake signal of
Z-axis;
X2= 1: set DO4 output as NO (normally
108
open) a-contact point; X2= 0: set DO4
output as NC (normally closed) b-contact
point;
X1X0=08: set pin 1 and pin 26 as BK+ and
BK- respectively.
DO5 corresponds to pin 28 & pin 27, used
as servo alarm signal.
X2= 0: set DO5 output as NC b-contact
007
point.
X1X0= 07: set pin 28 and pin 27 as
ALRM+ and ALRM- respectively.
