Function
setting for
P2-17
X2X1X0
100
External EMG stop input is not used.
digital input
pin DI8
DO4 corresponds to pin 1 & pin 26, used as
Function
clamping-position brake signal of Z-axis;
setting for
X2= 1: set DO4 output as NO (normally open)
P2-21
digital
X2X1X0
108
a-contact point; X2= 0: set DO4 output as NC
output pin
(normally closed) b-contact point;
DO4
X1X0=08: set pin 1 and pin 26 as BK+ and BK-
respectively.
Function
DO5 corresponds to pin 28 & pin 27, used as
setting for
servo alarm signal.
P2-22
digital
X2X1X0
007
X2=0: set DO5 output as NC b-contact point.
output pin
X1X0=07: set pin 28 and pin 27 as ALRM+ and
DO5
ALRM- respectively.
0: Servo ON must be triggered by numerical
2-51
Servo ON
(SON) setup
input signal.
0
1: when servo is powered, if there is no alarm
signal, servo will be on automatically.
Set 1 when there is no SON signal line.
