T3: cylinder 3 is opened
10.4.Programming Example
T1 (cylinder 1 is opened, while cylinder 2 and cylinder 3 are closed)
G00 X10 Y10 Z0
G01 X10 Y10 Z-5
G01 X110 Y10 Z-5
G01 X110 Y110 Z-5
G01 X10 Y110 Z-5
G01 X10 Y10 Z-5
G00 Z10
G00 X10 Y10
T2 (cylinder 2 is opened, while cylinder 1 and cylinder 3 are closed)
G00 X11 Y11 Z-5
G01 X109 Y11 Z-5
G01 X109 Y109 Z-5
G01 X11 Y109 Z-5
G01 X11 Y11 Z-5
G00 Z10
T3 (cylinder 3 is opened, while cylinder 1 and cylinder 2 are closed)
G00 X10 Y10 Z0
G01 X10 Y10 Z-5
G01 X110 Y10 Z-5
G01 X110 Y110 Z-5
G01 X10 Y110 Z-5
G01 X10 Y10 Z-5
G00 Z10
G00 X10 Y10
M5
