10. Function Information of Three-cylinder &
Single-transducer
When a NK105G2 is equipped with three-cylinder & single-transducer function, its differences in
ports and functions are listed in the following, while its other functions are the same as those of a
general NK105.
10.1. Ports
Silk-printed name
GY014 (SP+)
GY18
GY19
GY20
Table 8 Signal details of output ports
Signal
Remarks
Spindle
Cylinder 1
Cylinder 2
Cylinder 3
For connection with ON/OFF signals of transducer
Optical-coupler output
Optical-coupler output
Optical-coupler output
10.2.Related Parameters
Upper Position of Tool Change
Location: Menu→ 4. Oper Param→ 14. Tool Change→ 5. CTUpPosition; Unit: mm; Default value:
-1.000;
Function: to guard against breaking edge phenomenon during the change-over between two
cylinders, the Z axis moves up a certain height before a new cylinder is opened.
Tool Change Delay
Location: Menu→ 4. Oper Param→ 14. Tool Change→ 6. CTDelay; Unit: ms; Default value: 0ms;
Function: to avoid transducer alarm during change-over of cylinders; generally within 2~5.
Tool X (1, 2……)
Location: Menu→ 4. Oper Param→ 14. Tool Change→ 3. Tool Offset→ 1. Tool 1 (2. Tool 2);
Unit: mm; Default Value: 0;
Function: sets the offset between two tools to ensure that the two tools are on the same datum
point during machining.
10.3.Programming Instructions
T1: cylinder 1 is opened
T2: cylinder 2 is opened
