different offsets according to the corresponding tool No. to make machining in the same plane.
The second step is to fix workpiece origin. After X origin and Y origin are input, pressing
will set X and Y workpiece origins successfully. For any tool No., open a cylinder, manually adjust the
Z axis to make its knifepoint touch the workpiece surface, and then press
workpiece origin is fixed successfully.
+
. The Z
The third step is to start machining automatically by pressing
. After machining finishes, it
is necessary to only perform the second step and the third step again without performing the first step
on condition that only a new workpiece is replaced with no change of the tool.
9.7. Motion Process during Machining
During machining, in case of meeting T1 command, the system will move the Z axis to upper
position of tool change, open cylinder 1, change current tool No. to 1, and call the position offset of
Tool 1; in case of meeting M101 command, the system will open spindle 1 for machining; in case of
meeting M102 command, the system will close spindle 1; in case of meeting T2 command, the
system will close cylinder 1, move the Z axis to upper position of tool change, open cylinder 2, change
the current tool No. to 2, and call the position offset of Tool 2; in case of meeting M201 command, the
system will open spindle 2 for machining; after machining finishes, the system will close the current
cylinder and spindle.
