9. Function Information of Double-cylinder &
Double-transducer
When a NK105G2 is equipped with double-cylinder & double-transducer function, its differences
in ports and functions are listed in the following, while its other functions are the same as those of a
general NK105.
9.1. Ports
Table 7 Signal details of output ports
Silk-printed name
Signal
Remarks
GY013 (SP-)
GY014 (SP+)
GY18
GY19
Spindle 2
Spindle 1
Cylinder 1
Cylinder 2
For connection with ON/OFF signals of
transducer
For connection with ON/OFF signals of
transducer
Optical-coupler output
Optical-coupler output
9.2. Related Parameters
‹ Upper Position of Tool Change
Location: Menu→ 4. Oper Param→ 14. Tool Change→ 5. CTUpPosition; Unit: mm; Default value:
-1.000;
Function: to guard against breaking edge phenomenon during the change-over between two
cylinders, the Z axis moves up a certain height before a new cylinder is opened.
‹ Tool X (1, 2……)
Location: Menu→ 4. Oper Param→ 14. Tool Change→ 3. Tool Offset→ 1. Tool 1 (2. Tool 2);
Unit: mm; Default Value: 0;
Function: it sets the offset between two tools to ensure that the two tools are on the same datum
point during machining.
9.3. Programming Instructions
T1: cylinder 1 is opened
T2: cylinder 2 is opened
M101: spindle 1 is opened
M102: spindle 1 is closed
