The system detects hardware limit periodically under the main interface. When hardware limit
occurs, its prompt dialog is as shown in Fig. 8-8.
Limit! Exit
Manually.
OK
ESC
Fig. 8-8 Hardware limit dialog
At this time, press [Ok] key to make the system return to the main interface under “Jog” mode,
with “Limit Rls.” displayed at its bottom right corner, as shown in Fig. 8-9. Or you can press [ESC] key
to directly back to the main interface under “Jog” mode.
1X
15.617 Idle
1Y 551.107 SOff
1Z
9.900 Slow
Jog
Limit Rls.
Fig. 8-9 Prompt interface of limit release
Move the machine tool away from the limit position, “Limit Rls.” disappearing; the prompt
interface of limit release backs to the normal main interface.
