上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
2X
0.000 Idle
2Y
0.000 SOff
2Z
0.000 Slow
Jog
100%
Fig. 8-5 Main interface under G55 WCS
8.2. Automatic Processing
Automatic processing refers to that the system processes system files and the files in the USB
flash disk in terms of instructions, also called file processing. All the parameters of machine tool and
system should be set correctly before automatic processing starts.
8.2.1. Load Files
Load an Ordinary File
Press “Menu” key to enter menu page→ press “Up” and “Down” keys to select “Local Files” or
“USB Files”→ press [OK] key to enter the corresponding file list interface→ press [OK] key to select
the processing file to be machined→ press
to load the selected file
Load an ENG File with Tool Selection Function
Enter the file list according to the method to load an ordinary file, and then press [OK] key to
select the ENG file to be machined, and then press
automatically as shown in Fig. 8-6.
to enter tool selection interface
Number of tools: 2
Tool No.: 0
Cutter 1: [Flat Bottom]JD-6.00
Fig. 8-6 Tool selection interface
Number of tools: the number of tools in this ENG file
Tool No.: current tool No., selected by pressing “Up” and “Down” keys
Cutter: selected by pressing “Up” and “Down” keys, displaying tool sequence number and name
After parameters are set, press [OK] key to load the file; after loading, the system will return to
processing page automatically.
50
Specialized, Concentrated, Focused
