8. Processing Operations
Processing operations can be divided into two categories: manual processing and automatic
processing. Processing parameters and machining process can be adjusted conveniently in both
manual processing and automatic processing.
8.1. Manual Processing
Manual processing refers to manipulating the machine tool directly by the direction buttons of the
three axes on the panel. At the same time, the operation speed and step length, etc. can be adjusted
during operation according to the requirements of operation.
After backing to the reference point, the system will enter into manual state; screen display is as
shown in Fig. 8-1.
1X
0.000 Idle
1Y
0.000 SOff
1Z
0.000 Slow
Jog
100%
8.1.1.
Fig. 8-1 Manual processing interface
Mode Selection of Manual Processing
To satisfy the requirements of manual motion under different situations, this system provides two
kinds of manual motion modes: “Jog” and “Stepping”, which can be switched by pressing “Shift” key.
User can view the current motion mode through “processing mode” at the bottom of the screen.
Jog Motion Mode
There is no concrete data control under this mode. You can press a motion direction key（
,
,
,
,
,
）to move the machine tool accordingly under this mode. The
machine tool will not stop until the direction key is released. For the motion speed, it is decided by the
current type of speed (manual high speed and manual low speed). This motion mode is suitable for
coarse tuning of the position of mechanical coordinate.
Stepping Motion Mode
Under this motion mode, the machine tool will move accordingly after you press a motion
