7.8.2. Ports List
For the detailed introduction, see chapter 6.3.
7.8.3. Keypress Diag (Diagnosis)
This item is used to check whether keys can be used normally. After entering, the system will
display a prompt “press a key”. Press any key (except
) to show the name of the pressed key
on the screen, as shown in Fig. 7-20. If the pressed key is damaged and out of work, the screen will
not display its name or the wrong key name.
Current key:
Up
Fig. 7-20 Keypress diagnosis interface
Pressing
will exit from this page.
7.8.4. Inport Diag (Diagnosis)
This interface displays the polarities of the input ports, which can not be changed.
7.8.5. Outport Diag (Diagnosis)
This interface displays the polarities of output ports with water lamp display, which can not be
modified. The corresponding relation among system output terminal No., terminal board ports and
signals is listed in chapter 6.3 “Port Polarity”.
