Press:
0 Reboot
1 Shutdown
OK Cancel
Fig. 7-18 Reboot system interface
Execute the corresponding operation according to the prompt on the screen.
7.7.7. Exit
After the cursor is on this item, press [OK] key to eject a dialog box, in which pressing [OK] key
will exit from the system. And then the system goes blank. If you want to enter the system again, you
need to power off and re-power the system. In addition, you can also exit from the system by pressing
“1” in the interface shown in Fig. 7-18.
7.8. Diagnosis
Press “Menu” key→ select 8. Diagnosis by pressing “Up” or “Down” key, and then press [OK] key
to enter its interface, in which select a submenu by pressing “Up” or “Down” key.
The submenus under this interface are as shown in Fig. 7-19.
1. System Info
2. Port List
1. Software Ver.
2. Card No.
3. Remaining Time
4. Register Times
3. Keypress Diag
4. Inport Diag
5. Outport Diag
7.8.1.
Fig. 7-19 Submenu list of system diagnosis
System Info
In this page, you can view system software version, control card No., remaining time and
registered times. If an item is wrong, after pressing [OK] key for confirming selection, an error prompt
“Failed to Read Registration Info” will be displayed. At the same time, the other items can not read,
either.
