Enter Reg. Code
ABCDEFGHIJKLMNOP
QRSTUVWXYZ
Fig. 7-16 Registration code input interface
Register by entering the registration code in this interface. Select a letter (end-around) by
pressing “Up” and “Down” keys, and then press [OK] key for conformation; for the input of figure,
enter a figure by pressing the corresponding key. If the input is wrong, press
and then input the right letter or figure.
7.7.5. Help
to backspace,
After the cursor is on the item “5. Help”, press [OK] key to enter “Help Message Show Delay”
parameter setting interface as shown in Fig. 7-17. The value of this parameter is integer within the
range of 1~999999.
Spec.: Help message
show delay
Value: 10
Unit: S
Specification:
Fig. 7-17 Help setting interface
The system offers help function, introducing operation methods under such interfaces as
“Processing page” and “Port list”, in which pressing
+
will enter the corresponding
help interface. Or, the system will enter the corresponding help interface itself after a certain time set
under the interface shown in Fig. 7-17, when the system is under idle state.
7.7.6. Reboot
After the cursor is on this item, press [OK] key to eject its dialog box, in which press [OK] key to
reboot the system.
Or you can keep pressing [ESC] key for about 3 seconds in the main interface to eject the
following interface.
