上海维宏电子科技股份有限公司

Weihong Electronic Technology Co., Ltd.

1. Language

2. Export Log

3. System Update

4. Register

5. Help

6. Reboot

7. Exit

1. Chinese

2. English

7.7.1.

Language

Fig. 7-12 Submenu list of system upkeep

Currently, the system supports two kinds of language: Chinese and English, which can be

switched in the following interface.

1. Chinese

2. English

7.7.2.

Fig. 7-13 Chinese-English selection interface

Export Log

A Log.txt will be generated after the log is exported to the USB flash disk. After log export finishes,

“Log Exported Successfully” will be displayed on the screen. Press [OK] key or [ESC] key to return to

the previous menu.

7.7.3. System Update

After the cursor is on the “System Update” item, press [OK] key for confirmation, after which a

dialog will pop up asking whether to update the system. After pressing [OK] key again, a dialog as

shown in Fig. 7-14 will pop up.

Specialized, Concentrated, Focused
