the interior file or after upgrade finishes.

Operate following the prompts displayed on the screen. After recovery is successful, a cue to

reboot the system will be displayed on the screen, as shown in Fig. 7-10. At this time, you can press

[OK] to restart the system, or [ESC] to back to the previous menu.

The action of ex-factory parameter recovery won’t clear the parameters backup file. Therefore, if

this action is carried out accidentally and all the interior parameters are cleared, you can restore the

backup parameters by “Restore Backup”.

Note:

Modification to this item will not become effective until the system is rebooted.

7.6.4. Export Parameters

When software or hardware fault occurs, you can export parameters to the USB flash disk for

backup.

7.6.5. Import Parameters

Import the parameters in the USB flash disk to the system, avoiding repeatedly setting

parameters. After import is successful, the system will display a prompt of system reboot as shown in

Fig. 7-11.

Imported!

Restart?

ESC

Fig. 7-11 Prompt dialog of successful parameter import

7.7. System Upkeep

Press “Menu” key→ select 7. System Upkeep by pressing “Up” or “Down” key, and then press

[OK] key to enter its interface, in which select a submenu by pressing “Up” or “Down” key.

The submenus under this interface are as shown in Fig. 7-12.
