7.6. Param Upkeep (Parameter Maintenance)
Press “Menu” key→ select 6. Param Upkeep by pressing “Up” or “Down” key, and then press [OK]
key to enter its interface, in which select a submenu by pressing “Up” or “Down” key.
The submenus under this interface are as shown in Fig. 7-9.
1. Backup Params
2. Restore Backup
3. Factory Params
4. Export Params
5. Import Params
7.6.1.
Fig. 7-9 Submenu list of parameter upkeep
Backup Parameters
Press [OK] key to confirm backing up the parameter. No matter the parameter backup is
successful or failed, a prompt will be displayed.
7.6.2. Restore Parameter Backups
It is used to restore the backup parameters. If the parameter has not been backed up, “Backup
File Not Found!” will be displayed.
If the recovery is successful, a prompt of rebooting system will be displayed, as shown in Fig.
7-10. At this time, you can press [OK] key to reboot the system directly, or [ECS] to return to the
previous menu.
Reboot
Immediately?
OK
ESC
7.6.3.
Fig. 7-10 Prompt dialog of system reboot
Restore Factory Parameters
The action of ex-factory parameter recovery is to clear all the data and parameters interiorly set
stored in system memory chip. It is necessary to perform this action when there are messy codes in
