‹ Lubrication Setting
Parameter
Enable Auto Lube
Time Interval
Duration
Meaning
Lube
Whether to open lubrication pump automatically
at fixed period
Time interval to open lubrication pump after
machine tool start-up
Time to release lubrication oil each time
Setting range
Yes: valid
No: invalid
0~34560000s
0~34560000s
‹ Parameters Related with Algorithm
Parameter
Meaning
Setting range
Enable S Algo
Whether to adopt acceleration/deceleration of Yes: valid
S-type algorithm
No: invalid
Arc Increment Whether to adopt arc increment mode
Yes: valid
No: invalid
Used to set the max. forward looking segments
Forward Look Seg when calculating connection speed
0~10000
In arc increment mode, the coordinate of circle centre is relative to the starting point. Otherwise, it is
relative to workpiece origin.
‹ Compensation Parameters
Parameter
Meaning
Setting range
Backlash Set
Yes: valid
Compensation ON Whether to enable backlash compensation
No: not execute backlash
compensation
The backlash compensation amount of X, Y
Axis Backlash and Z axes, valid only when “Compensation 0~1000000mm
On” is set “Yes”
Generally, spindle is fixed on the lead screw whose outer wire and the inner wire on the outer wire can
not be completely matched, backlash compensation compensates the clearance between the lead
screw of last direction that the spindle needs to finish after reversing its moving direction.
