‹ Command Ignoring
Parameter
Ignore F Code
Ignore S Code
Meaning
Whether to use the feedrate command
in the program
Whether to use the spindle command
in the program
Setting range
Yes: use the feedrate in the system
No: use the feedrate in the file
Yes: use the spindle command in the
system
No: use the spindle command in the
file
7.5. Mfr Param (Manufacturer Parameters)
‹ Velocity Parameters
Parameter
Decel. Dist.
Approach Speed
Sgl Axis Acc.
Max. Turn Acc.
Jerk
Max. Speed of Z
Enbl Plunge Rate
Z Plunge Cut Spd
Ref Cir Radius
Meaning
Spindle Stop
To protect tools, the machine tool will
decelerate (at [approach speed]) when
approaching the target position during
positioning. This parameter is used to
specify the distance from the decelerating
position to the target position.
It is the feed speed of too when
approaching workpiece during positioning
(the distance between tool and workpiece
is smaller than deceleration distance).
Description of the acceleration/
deceleration capability of each feed axis,
with unit “mm/s2”
The max. acceleration of feed motion on
adjacent axes
The change rate of acceleration of single
axis (acceleration’s acceleration)
It specifies the max. allowable speed of Z
axis.
Whether to adopt the plunge cut speed
under plunge cut of G01
The plunge cut speed under plunge cut of
G01
None
Setting range
0~999mm
Start speed ~ processing speed
0.001~100000.0mm/s2
0.001~100000.0 mm/s2
0.001~100000.0 mm/s3
0.06~100000.0 mm/min
Yes: valid
No: invalid
0~Max. Speed of Z
0.001~100000.0mm
36
