Backing to mechanical origin before processing can prevent processing deviation, ensuring position
accuracy. It is recommended to set “Back REF First” as “Yes” to disable machine tool to run
automatically if backing to mechanical origin is not executed before processing. When backing to
mechanical origin can not be executed due to origin fault, “Back REF First” can be set as “No”.
G73_G83 Retract: the retract amount after each feed under G73 command; under G83 command, the
distance between the point from fast drilling to peck during each descending of tool interrupted feed
and the descending point of last cutting feed.
‹ Parameters Related with Offset
Parameter
Meaning
Setting range
Public Offset
Aiming at all the coordinate systems, used for
adjusting workpiece origin of X, Y and Z axes
-10000~10000
Work Offset D-value of WCS origin and MCS origin
-10000~10000
For the detailed information, refer to chapter 4.2.
The relation of workpiece offset, tool offset and public offset is as following:
Workpiece coordinate = Mechanical coordinate - Workpiece offset – Tool offset – Public offset
‹ Spindle Parameters
Parameter
Meaning
Setting range
Spindle Stop
SOff at pause Whether to stop spindle at pause
Yes: stop
No: not stop
SOff at Stop Whether to stop spindle at stop
Yes: stop
No: not stop
SOff at End
Whether to stop spindle when processing
finishes
Yes: stop
No: not stop
This group of parameters sets whether to stop spindle under various forms of stop state.
‹ File Parameters
Parameter
Lifting Height
Tool Change Tip
Cycle Times
Deep Hole Mode
Meaning
Eng Params
It sets the tool lifting height of Z axis during
rapid traverse of machine tool when an ENG
file is being processed.
It sets whether to pause and prompt tool
change when tool change command is
encountered during ENG file processing.
It sets the cycle times to process an Eng file.
Mode selection for deep hole machining
Setting range
0~99999
Yes: valid
No: invalid
0~100000
0: reciprocating chip removal
1: high-speed reciprocating chip
removal
34
